GE IC693MDL742J | GE 24V DC Positive Logic Input Module

Features

High Density Inputs: Provides 16-point digital inputs for applications requiring high density inputs.

Positive Logic Inputs: Positive logic inputs, i.e., a high input signal indicates a “1”.

LED Indicators: Each input point has LED indicators for easy status monitoring and troubleshooting.

Modular design: Easy to install and maintain, can be seamlessly integrated with other 90-30 series modules.

Advantages

Flexibility: The modular design allows for flexible configurations to meet specific needs and adapt to different application scenarios.

Reliability: GE products are known for their high reliability and durability in a variety of industrial environments.

Easy to Integrate: Highly compatible with other modules in the 90-30 series, they are easy to integrate into existing systems.

Global Support: GE provides technical support and after-sales service worldwide to ensure that users have no worries during use.

Parameters

Input Points: 16 points

Input Voltage: 24V DC

Input Current: 7mA (24V DC)

Response time: ON→OFF: 1ms max, OFF→ON: 1ms max

Insulation resistance: 20MΩ or more (500V DC)

Withstanding voltage: 500V AC, 1 minute (between input terminal and PLC internal circuit)

Operating temperature: 0°C to 55°C

Storage temperature: -40°C to 85°C

Application Scenarios

Industrial Automation: Suitable for various industrial automation control systems, such as production lines, packaging equipment, conveyor systems, etc.

Process Control: Can be used for signal acquisition and processing in process control systems.

Building Automation: Used in building automation system to monitor and control various devices.

Mechanical Manufacturing: Applicable to various control tasks in mechanical manufacturing, such as machine tools, robots, and so on.

Summary

The IC693MDL742J is a high-performance, highly reliable digital input module for a variety of complex industrial automation and process control tasks. Its modular design and high-density inputs make it ideal for use in industrial automation, and its competitiveness in the marketplace is further enhanced by the GE brand of global support and service.

Details of GE IC693MDL742J | GE 24V DC Positive Logic Input Module
